1. Product Features
n Fast installation
- Product size is standard 96 panel type
- Installation method is a snap on type, without screws
n Support multiple current transformer connections
- The ME337N series supports a new type of current transformer – rogowski coil direct connection, without the need for an external integrator
- The ME337N series supports voltage output type current transformer connection simultaneously
- The ME337C series supports direct current connection, with a maximum connection current of 7A
n Support multiple power grid systems
- Supports three-phase four wire, three-phase three wire, one phase three phase, and single-phase systems
n Multiple power supply options available
- Available in 220VAC, 24VDC and 12VDC power supplies
n Support voltage and current harmonic measurement
- Supports voltage, current, fractional harmonics, up to 50 measurements
- Support voltage and current harmonic distortion and harmonic value measurement
- Support voltage and current total harmonic distortion measurement
n More features
- Support 6 rate tariff energy, support RTC switching or manual switching
- Support demand measurement
- Support alarm setting
- Support current transformer orientation modification
- Support current channel modification
